Product Introduction
The salt licking briquetting machine is to process the mineral elements, vitamins and other trace elements and nutrients required by large livestock such as cattle and sheep into blocks, cakes and other special shapes through a scientific formula. A kind of feed that cattle and sheep lick, its shape is different, some are cylindrical, some are rectangular and square. Also known as block compound additives, usually referred to as "licking block" or "licking brick".
working principle
The salt licking block briquetting machine is a four-column hydraulic press with high pressure and high accuracy. This press adopts the integrated control of machine, electricity, hydraulic and gas, with automatic feeding device, floating pressurization, so that the product forming density can be effectively controlled, and the hydraulic system adopts combined superimposed valve blocks to ensure the continuous and frequent stable operation of the hydraulic press; The positioning of mechanical stoppers and stepless adjustment mechanism at the three positions of loading, forming and demoulding ensure that the geometric dimensions of the product are stable and adjustable. Equipped with oil cooling device. PLC and man-machine interface centralized control are adopted, and mechanical limit device is installed at the same time, so as to ensure the consistency of products.
Machine composition
The main components of the automatic salt licking block briquetting machine:
①Main engine: It is composed of frame, main hydraulic cylinder, pusher hydraulic cylinder, bottom plate hydraulic cylinder, supporting mold frame, mold, pressure head, etc.
②Hydraulic station: It is composed of motor, hydraulic pump, pump protection device, control valve block and piping system connected to the briquetting machine.
③Console: It is composed of electrical system and plc control system.
Finished product display
